Description
PHONO 2 is the Bluenote flagship Phono preamplifier uses the Bluenote Inductive-Phono™power supply virtually works as a DC battery and the most sophisticated version of the Phono-Wide™ electronic design excellent matching with almost all the cartridges available on the market today, without the user needing to make any manual adjustments.
Though the construction of the PHONO 2
chassis uses the Phono 1 knowledge, a no magnetic internal dampening is been applied
to ensure the highest sonic performance.
The special Inductive-Phono™ power supply
is a real inductive power supply uses Three
E-Core Transformers. Two E-Core
Transformers work as AC dampers to let the
unit be powered by a virtual DC battery,
obtaining a very silent audio signal path.
Obviously all the electronic components are
strictly selected and tested to have a real low
tolerance not to loose the PHONO 2 high
quality properties.
Features:
FREQUENCY RESPONSE: 20Hz - 20KHz @ +/- 1dB
- THD: 0,05% @ 20Hz – 20kHz
MC INPUT IMPEDENCE: 470ohm (extra resistors supplied to adjust finely load)
MM INPUT IMPEDENCE: 47kohm
INPUT SENSIVITY: MC From 0,1mV to 0,5mV - MM: From 0,6mV to 6,0mV var. acceptance
GAIN: MC>70dB - MM: >48dB on all RIAA diagram
RATIO SIGNAL TO NOISE: -89dB
DIMENSIONS: 130mm L x 110mm H x 240mm D
WEIGHT: Kg. 4,00
Handmade in Italy.
