Description
Technical Details
Manufacturer
DJI
Brand
DJI
Model
DJI-MVM400P-C3
Product Dimensions
14.81 x 9.4 x 6.4 cm; 950 g
Batteries
1 Lithium Polymer batteries required. (included)
Item model number
CP.MA.00000740.01
Manufacturer Part Number
CP.MA.00000740.01
Mirror Adjustment
Remote Control
Special Features
Face Detection, Digital Filters, 3D Capture, Gps
Item Weight
950 g
Additional Information
ASIN
B0CFLKK7QS
Customer Reviews
4.6 4.6 out of 5 stars 733 ratings
4.6 out of 5 stars
Date First Available
26 September 2023
About this item
Compact and Portable Lightweight, portable, and palm-sized when folded, weighing less than half a bottle of water
Regulation-Friendly For aircraft under 250 g, registration or certification is not required in most countries and regions.
Wide Detection Range Real-time obstacle detectioneffectively reduces collision risks
More Stable Hovering A pair of downward vision sensors and a more precise 3D ToF sensor facilitate more stable hovering
Key Features
Up to 4K100 Video & 48MP Raw Stills
Omnidirectional Obstacle Avoidance
Regulation-Friendly 249g Weight
RC 2 Controller Included
Up to 34 Minutes of Flight Time
Rotating Gimbal for Vertical Shooting
Up to 12.4-Mile Range with OcuSync 4
FocusTrack Subject Tracking System
Automatic Shooting Modes
Foldable Design for Easy Travel/Storage
Specification
Aircraft
Takeoff Weight
249g
Dimensions
Folded (without propellers): 148×94×64 mm (L×W×H) Unfolded (with propellers): 298×373×101 mm (L×W×H)
Max Ascent Speed
5 m/s (S Mode) 5 m/s (N Mode) 3 m/s (C Mode)
Max Descent Speed
5 m/s (S Mode) 5 m/s (N Mode) 3 m/s (C Mode)
Max Horizontal Speed
16 m/s (S Mode) 12 m/s (N Mode) 12 m/s (C Mode)
Max Takeoff Altitude
4000m
Max Flight Time
34 minutes (with Intelligent Flight Battery)
Max Hovering Time
30 minutes (with Intelligent Flight Battery)
Max Flight Distance
18 km (with Intelligent Flight Battery and measured while flying at 40.7 kph)
Max Wind Speed Resistance
10.7 m/s
Max Tilt Angle
35°
Operating Temperature
-10° to 40° C (14° to 104° F)
Global Navigation Satellite System
GPS + Galileo + BeiDou
Hovering Accuracy Range
Vertical: ±0.1 m (with vision positioning) Horizontal: ±0.1 m (with vision positioning)
Internal Storage
2 GB
Camera
Image Sensor
1/1.3-inch CMOS, Effective Pixels: 48 MP
Lens
FOV: 82.1° Format Equivalent: 24 mm Aperture: f/1.7 Focus: 1 m to ∞
ISO Range
Video: 100-6400 (Normal) 100-1600 (D-Log M) 100-1600 (HLG) Photo: 100-12800 (Normal)
Shutter Speed
12MP Photo: 1/16000-2 s 48MP Photo: 1/8000-2 s
Max Image Size
8064×6048
Still Photography Modes
Single Shot: 12 MP and 48 MP Burst Shooting: 12 MP, 3/5/7 frames; 48 MP, 3 frames Automatic Exposure Bracketing (AEB): 12 MP, 3/5/7 frames at 0.7 EV step; 48 MP, 3 frames at 0.7 EV step Timed: 12 MP, 2/3/5/7/10/15/20/30/60 s; 48 MP, 5/7/10/15/20/30/60 s
Photo Format
JPEG/DNG (RAW)
Video Resolution
4K: 3840×2160@24/25/30/48/50/60/100fps FHD: 1920×1080@24/25/30/48/50/60/100/200*fps
Video Format
MP4 (MPEG-4 AVC/H.264, HEVC/H.265)
Max Video Bitrate
H.264/H.265: 150 Mbps
Supported File System
exFAT
Color Mode
Normal: 8-bit 4:2:0 (H.264/H.265) HLG/D-Log M: 10-bit 4:2:0 (H.265)
Digital Zoom
12MP Photo: 1-2x 4K: 1-3x FHD: 1-4x
Gimbal
Mechanical Range
Tilt: -135° to 80° Roll: -135° to 45° Pan: -30° to 30°
Controllable Range
Tilt: -90° to 60° Roll: -90° or 0°
Sensing
Sensing Type
Omnidirectional binocular vision system, supplemented with a 3D infrared sensor at the bottom of the aircraft
Forward
Measurement Range: 0.5-18 m Detection Range: 0.5-200 m Effective Sensing Speed: Flight Speed ≤ 12 m/s FOV: Horizontal 90°, Vertical 72°
Backward
Measurement Range: 0.5-15 m Effective Sensing Speed: Flight Speed ≤ 12 m/s FOV: Horizontal 90°, Vertical 72°
Lateral
Measurement Range: 0.5-12 m Effective Sensing Speed: Flight Speed ≤ 12 m/s FOV: Horizontal 90°, Vertical 72°
Upward
Measurement Range: 0.5-15 m Effective Sensing Speed: Flight Speed ≤ 5 m/s FOV: Front and Back 72°, Left and Right 90°
Downward
Measurement Range: 0.3-12 m Effective Sensing Speed: Flight Speed ≤ 5 m/s FOV: Front and Back 106°, Left and Right 90°
Video Transmission
Video Transmission System
O4
Live View Quality
Remote Controller: Up to 1080p/60fps (available when the aircraft is flying in Photo or Video mode) Up to 1080p/30fps (available when the aircraft is flying in Video mode) Up to 1080p/24fps (available when the aircraft is in standby mode on the ground)
Operating Frequency
2.4000-2.4835 GHz 5.170-5.250 GHz 5.725-5.850 GHz
Transmitter Power (EIRP)
2.4 GHz: < 33 dBm (FCC) < 20 dBm (CE/SRRC/MIC) 5.1 GHz: < 23 dBm (CE) 5.8 GHz: < 33 dBm (FCC), < 30 dBm (SRRC), < 14 dBm (CE)
Max Transmission Distance (free of interference)
FCC: 20 km CE: 10 km SRRC: 10 km MIC: 10 km
Max Transmission Distance (with interference)
Strong Interference: urban landscape, approx. 1.5-4 km Medium Interference: suburban landscape, approx. 4-10 km Low Interference: suburb/seaside, approx. 10-20 km
Max Download Speed
O4: 10 MB/s (with DJI RC-N2) 10 MB/s (with DJI RC 2) Wi-Fi 5: 30 MB/s
Lowest Latency
Aircraft + Remote Controller: approx. 120 ms
Antenna
4 antennas, 2T4R
Battery
Capacity
Intelligent Flight Battery: 2590 mAh
Weight
Intelligent Flight Battery: approx. 77.9 g
Nominal Voltage
Intelligent Flight Battery: 7.32 V
Max Charging Voltage
Intelligent Flight Battery: 8.6 V
Type
Li-ion
Energy
Intelligent Flight Battery: 18.96 Wh
Charging Temperature
5° to 40° C (41° to 104° F)
Charging Time
Intelligent Flight Battery: 70 minutes (with the DJI 30W USB-C Charger and the battery mounted to the aircraft), 58 minutes (with the DJI 30W USB-C Charger and the battery inserted into the Two-Way Charging Hub)
