Height, Width, and Depth (Standing): 1270x450x200mm
Height, Width, and Depth (Folded): 690x450x300mm
Weight with Battery: Approx. 35kg
Total Degrees of Freedom (Articulated Motors): 23
Single Leg Degrees of Freedom: 6
Waist Degrees of Freedom: 1
Single Arm Degrees of Freedom: 5
Maximum Knee Joint Torque: 90 N.m
Maximum Arm Load: 2kg
Lower Leg + Thigh Length: 0.6m
Arm Span: Approx. 0.45m
"Extra-Large Joint Movement Space: Waist Z-axis Joint: ±155°
Knee Joint: 0~165°
Hip Joint: P±154°, R-30~+170°, Y±158°"
Hollow Internal Wiring in All Joints: Yes
Joint Encoder: Dual Encoders
Cooling System: Localized Air Cooling
Power Supply: 13-cell Battery
Basic Computing Power: 8-core High-Performance CPU
Sensing Sensors: Depth Camera D435i *1 + 3D LiDAR *1
WiFi 6, Bluetooth 5.2: Includes standard stereo speakers and microphone array; 1 charger, 1 smart battery (quick-release); 1 handheld remote control; Battery life: approx. 2 hours; Smart OTA upgrade: supported; Secondary development: none; Warranty period: 8 months.
