Features
Durable ABS construction with full-face grille
IP54 rated
Integral mounting bracket - included
Seismic restraint tethers - included
6.5” LF driver with 1” dome HF tweeter
Low impedance and transformer versions available
i6T : 70v : 12.5w / 25w / 50w
i6T : 100v : 25w / 50w
i6 : 50w RMS, 100w Programme, 200w Peak
i6 : 8Ω impedance
For distributed music, paging and speech
Tech Specs
System Type Passive
Configuration Two-way
Frequency Response (+/-3dB) 70Hz - 20kHz
Frequency Range (-10dB) 50Hz - 20kHz
Sensitivity (2.83v/1m) 86dB
Calculated Maximum SPL @1m 109dB
System Rated Impedance 8Ω
Size 6.5"
Voice Coil Size 1"
Rated Impedance 8Ω
LF Power (re:AES2-2012) 50W
HF Driver Type Soft dome tweeter
Voice Coil Size 1"
Diaphragm Material Silk
Rated Impedance 8Ω
HF Power (re:AES2-2012) 10W
Nominal Coverage (H x V) 150° x 170°
System Continuous Power 50w
System Programme Power 100w
System Peak Power 200w
Crossover frequency 2.2kHz
Input Connector Phoenix terminal
Height 370mm/14.6"
Width 245mm/9.6"
Depth 216mm/8.5"
